Modified natural materials will be an essential component of a sustainable future, but first a detailed understanding of their properties is needed. The way heat flows across bamboo cell walls has been mapped using advanced scanning thermal microscopy, providing a new understanding of how variations in thermal conductivity are linked to the bamboo’s elegant structure. The findings, published in the journal Scientific Reports, will guide the development of more energy-efficient and fire-safe buildings, made from natural materials, in the future.

Nature is an amazing architect. Bamboo is structured in a really clever way.

Darshil Shah

The building sector currently accounts for 30-40% of all carbon emissions, due to both the energy-intensive production of the materials (predominantly steel and concrete), and the energy used in heating and cooling the finished buildings. As the global population grows and becomes increasingly based in towns and cities, traditional building approaches are becoming unsustainable.

Renewable, plant-based materials such as bamboo have huge potential for sustainable and energy-efficient buildings. Their use would dramatically reduce emissions compared to traditional materials, helping to mitigate the human impact on climate change. This approach would also help keep carbon out of the atmosphere by diverting timber away from being burnt as fuel.

The study involved scanning cross-sections of bamboo vascular tissue, the tissue that transports fluid and nutrients within the plant. The resulting images revealed an intricate fibre structure with alternating layers of thick and thin cell walls. Peaks of thermal conductivity within the bamboo structure coincide with the thicker walls, where chains of cellulose – the basic structural component of plant cell walls – are laid down almost parallel to the plant stem. These thicker layers also give bamboo its strength and stiffness. In contrast, the thinner cell walls have lower thermal conductivity due to cellulose chains being almost at a right angle to the plant stem.

“Nature is an amazing architect. Bamboo is structured in a really clever way,” said Darshil Shah, a researcher in Cambridge University’s Department of Architecture, who led the study. “It grows by one millimetre every ninety seconds, making it one of the fastest growing plant materials. Through the images we collected, we can see that it does this by generating a naturally cross-laminated fibre structure.”

While much research has been done on the cell structure of bamboo in relation to its mechanical properties, almost none has looked at how cell structure affects the thermal properties of the material. The amount of heating and cooling required in buildings is fundamentally related to the properties of the materials they are made from, particularly how much heat they conduct and store.

A better understanding of the thermal properties of bamboo provides insights into how to reduce the energy consumption of bamboo buildings. It also enables modelling of the way bamboo building components behave when exposed to fire, so that measures can be incorporated to make bamboo buildings safer.

“People may worry about fire safety of bamboo buildings,” said Shah. “To address this properly we have to understand the thermal properties of the building material. Through our work we can see that heat travels along the structure-supporting thick cell wall fibres in bamboo, so if exposed to the heat of a fire the bamboo might soften more quickly in the direction of those fibres. This helps us work out how to reinforce the building appropriately.”

At present, products such as laminated bamboo are most commonly used as flooring materials due to their hardness and durability. However, their stiffness and strength is comparable to engineered wood products, making them suitable for structural uses as well. “Cross-laminated timber is a popular choice of timber construction material. It’s made by gluing together layers of sawn timber, each at a right angle to the layer below,” said Shah. “Seeing this as a natural structure in bamboo fibres is inspiration for the development of better building products.”

The team of researchers, from the University of Cambridge and the University of Natural Resources and Life Sciences Vienna, also plans to look at what happens to heat flow in bamboo when its surface is burned and forms char. The use of scanning thermal microscopy to visualise the intricate make-up of plants could also be useful in other areas of research, such as understanding how micro-structural changes in crop stems may cause them to fall over in the fields resulting in lost harvests.

Shah is a member of the University of Cambridge’s interdisciplinary Centre for Natural Material Innovation, which aims to advance the use of timber in construction by modifying the tissue-scale properties of wood to make it more reliable under changing environmental conditions.

The research was funded by the Leverhulme Trust, the Austrian Science Fund and the Lower Austrian Research and Education Society.

Shah, al: “Mapping thermal conductivity across bamboo cell walls with scanning thermal microscopy.” Scientific Reports (2019). DOI: 10.1038/s41598-019-53079-4



Researcher profile: Dr Darshil Shah


Dr Darshil Shah is a Lecturer in the Department of Architecture who loves nature. “Nature is the master creator and architect!” he says. “My research is focused on how we can better use our natural resources to produce sustainable materials, which can be used in high-end and high-performance applications.”

He studied Mechanical Engineering with Mathematics at the University of Nottingham, where a summer internship sparked his interest in real-world design.

“As an undergraduate student I had a fantastic opportunity to work on the design and manufacture of a five kilowatt wind turbine for the campus,” says Shah. “The day we installed it was so exciting. It made me realise the impact my work could have, and the importance of joining together fundamental and applied research.”

Shah’s subsequent PhD, on the low-cost manufacture of wind turbine blades for small-scale turbines, led him to think about using greener materials to avoid the blades ending up in landfill at the end of their life. He also spent time in Oxford University’s Silk Group, where he learned about natural materials.

“My time at Oxford plunged me into a whole new world. I started thinking about how our materials and built environment could be informed and inspired by the natural world – from the beautiful silk threads and webs of spiders and silkworms, to the magnificent ivory tusks of elephants,” he says.

In Cambridge, Shah is exploring how to use a wide range of virgin and waste bioresources, such as timber, bamboo and waste date palm fibres, to help create sustainable products - from buildings to boats.

“At the fundamental level I’m exploring natural materials and structures for inspiration,” he says. “At the applied level, I’m working with industry to optimise materials for various sectors, from construction to transport.”

Shah believes that breaking boundaries between disciplines, particularly arts and humanities, and science and technology, is the only way to truly tackle some of the global challenges we face.

“Cambridge has a rich mix of brilliant researchers, thinkers and doers,” he says. “I’ve made connections in so many different departments, and had the chance to work on a fantastic variety of projects that I don’t think would have been possible anywhere else.”
